EN388:2003 Vs EN388:2016 - What Is The Difference?

EN388:2003 Vs EN388:2016 - What Is The Difference?

The Difference Between the EN388:2003 and the EN388:2016 Safety Glove Standards



EN388:2003 Protective Gloves Against Mechanical Risk is the globally recognised standard for protective gloves against mechanical risks. AS/NZS 2161.3:2005 mirrors EN 388:2003 and has been reconfirmed in Australia in 2016 and remains current in New Zealand.



EN388:2016 released in November 2016 has replaced En388:2003 in Europe. Testings on resistance to abrasion, tear and puncture are carried out as they were before with minor clarifications to testing procedures and materials. The test results correspond the same way they did in the 2003 version with ratings of 0-4, with 4 being the highest performance level.



The main difference in the 2016 edition is in relation to cut resistance and impact protection. The new version now has two cut-resistant methods:





Cut Resistance Testing



1. Existing Method - (Coup method)



Under the EN 388 glove standard, introduced in 2003, cut resistance is measured with a Coup test machine. A section of fabric is placed in a holder and a rotating circular blade is moved back and forth at a constant speed, pressing down with a force of 5 Newtons. When the blade cuts through, a performance rating from 1 to 5 is calculated from the total distance of travel. The blade gradually loses sharpness, so at the start and finish it is calibrated using cotton fabric. Therefore, the result can be less accurate for gloves with a higher cut-resistance. This test method remains in the 2016 version but is only to be used for materials that do not affect the sharpness of the blade.



2. New Method - EN ISO 13997 (TDM method)



TDM is an abbreviation for the equipment used to conduct this test, a tomodynamometer. This test involves a straight blade being drawn across the sample in one movement, with a new blade every time. The 'stroke length' before cut-through is recorded for a range of forces and graphs plotted to predict the force required to cut through the glove in 20mm of travel. This force is used to calculate a score from A to F, with F being the highest rating.

Impact Protection



Impact verification has been added to EN 388: 2016. The test method is taken from the motor cycle standard EN 13594:2015. The area where the impact protection is claimed to be tested, but due to technical reasons, the area around the fingers cannot be tested.



With impact energy of 5 joules, the transmitted force should be equal to or less than 9kN for a single hit and average should be equal or less than 7kN. If the requirements are fulfilled, the glove will be marked with a P (Pass). If a fail, there will be no marking.





Glove Markings and Levels of Performance

AS/NZS 2161.3:2005 which mirrors the EN 388:2003 version has not been revised to mirror the 2016 edition at the time this blog is written. Elliotts will, however, be progressively testing out cut resistant and impact resistant gloves to these new standards and will be displaying those results on our website in due course.

CONTACT US

See our range of Safety Gloves and Hand Protection Gear. For more information and to find the perfect hand protection, contact us today, at 07 3265 2944 or you can use our Contact Form, to request our current safety work glove brochure.
